PRODUCT DETAILS
Automatic firewood processor with 19HP KAMA diesel engine, electric start, equipped with a 1065mm circular saw, with max. 450mm splitting diameter and 610mm splitting length, 35 ton splitting force, towable with trailer coupler and wheels.
Optional accessories as below:
* 3m firewood discharge belt conveyor
* hydraulic log table with chain to load wood into machine, best works with a forklifter
* hydraulic log lifter to load wood into machine with max lifting weight of 800 kg
* 4 way splitting wedge (6-way, 8-way, 12-way wedge optional)
| Model name | BRT35T450 |
| Engine Type | Diesel engine |
| Engine brand | KAMA |
| Engine power (HP) | 19 |
| Engine start | Electrical start |
| Splitting force (T) | 35 |
| Length of feeding wood (mm) | 1000-6000 |
| Diameter of feeding wood (mm) | 450 |
| Max length of splitting wood (mm) | 610 |
| Max diameter of splitting wood (mm) | 450 |
| Blade diameter (mm) | 1065 |
| Blade rotate speed (rpm) | 2000 |
| Wedge with hydraulic adjust | 4-way |
| Adjustable height of wedge (mm) | 150 |
| Max lifting weight of lifter (kg) | 800 |
| Control valve | 5-handle, 14-Directional |
| Oil pump flux (GPM) | 32 |
| Oil tank capacity (L) | 52 |
| Ram speed / hydraulic cycle (s) | 6 |
| Tyre diameter (mm) | 500 |
| Machine size (L*W*H, mm) | 3200*1550*1590 |
| Package size (L*W*H, mm) | 2500*1800*2100 |
| Weight N/G. (kg) | 1100/1240 |
PICTURES
Package & Shipping
PACKAGE: Iron PALLETS with PE films
Port: Qingdao
